| Specificații hardware |
| Versiunea hardware |
3 |
| porturi |
Copper: One 10/100/1000BASE-T port
Fiber: Two 1000BASE-X SFP slots |
| Cablu |
Twisted-pair
10BASE-T: 2-pair UTP Cat3,4,5, up to 100 meters
100BASE-TX: 2-pair UTP Cat5, 5e up to 100 meters
1000BASE-T: 4-pair UTP Cat5e,6 up to 100 meters
Fiber-Optic Cable
50/125μm or 62.5/125μm multi-mode fiber cable, up to 220 and 550 meters
9/125μm single-mode cable with distance of 10/15/20/30/40/50/60/70/120km or longer (may vary on SFP module) |
| Afișaj LED |
System: One Power LED (Green)
Fiber Port: Two LNK/ACT LED (Green)
TP Port: One Speed LED (Green) , One LNK/ACT LED (Orange) |
| Schema de procesare a comutatorului |
Store and Forward |
| Țesătură |
6Gbps |
| Capacitatea de transfer (pachet pe secundă) |
4.4Mpps |
| Dimensiunea maximă a pachetului |
10K Bytes |
| Controlul debitului |
Back pressure for half-duplex. IEEE 802.3x pause frame for full-duplex |
| Cerinte de putere |
5V DC, 2A max. |
| Consumul de energie |
4 watts/13.6BTU per hour max. |
| Dimensiuni (L x Î x H) |
94 x 70 x 26 mm |
| Greutate |
180g (device only) |
| Conformitate standard |
| EMI Safety |
FCC Class B, CE |
| Mediu de lucru |
0 ~ 50 degrees C |
| Mediul de stocare |
-10 ~ 70 degrees C |
| Umiditatea de funcționare |
5 ~ 95%, Relative Humidity, non-condensing |
| Depozitare Umiditate |
5 ~ 95%, relative humidity (non-condensing) |
| Standard de conformitate |
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000BASE-SX/LX
IEEE 802.3x Flow Control |
