| Port serial |
| Interfață |
RS-232 x 1
RS-422 / RS-485 x 1
|
| Conector |
DB9 for RS-232
Terminal block for RS-422 / RS-485
|
| Rata baudului (rata de date) |
300bps to 230400bps |
| Mijloace de date |
5,6,7,8 |
| Tipul de paritate |
1, 1.5/2 |
| Opriți Bit |
Odd, Even, None, Space, Mark |
| Controlul debitului |
Hardware, None |
| semnale |
RS-232: DCD, RxD, TxD, GND, RI
RS-422: Tx+, Tx-, Rx+, Rx-
RS-485: Data A (+), Data B (-)
|
| Port Ethernet rapid |
| Standard |
10/100Base-TX |
| Conector |
RJ-45 |
| Distanţă |
100m |
| Cablu |
Twisted-pair |
| Hardware |
| Indicatoare LED |
System: Power 1, Power 2, Fault
TP or Fiber Port: Link / Active
Serial Port: Serial port mode, RS-232, RS-422 or RS-485
|
| administrare |
Web Management
PLANET Smart Discovery Utility
VCOM
|
| Mod de operare |
TCP Server
TCP Client
UDP Client
Virtual COM
Telnet Server
Pair Connection – Remote (Slave)
Pair Connection – Local (Master)
|
| Dimensiune (L x Î x H) |
135 x 97 x 32 mm |
| Greutate |
425g |
| Alimentare electrică |
12~48 VDC, Redundant power with polarity reverse protection function |
| Consumul de energie |
10.1 Watts / 34.44 BTU (max) |
| Instalare |
DIN rail kit and wall mount ear |
| Alarma |
Provides one relay output for power fail, Alarm Relay current carry ability: 1A @ DC 24V |
| Mecanic |
Metal |
| Mediu inconjurator |
Operating Temperature: -10~60 Degree C
Storage Temperature: -20~75 Degree C
Operating Humidity: 10~90% RH
Storage Humidity: 5~90% RH
|
| Emisiile |
FCC Class A, CE Certification Class A |
| Standarde |
IEEE 802.3 10Base-T,
IEEE 802.3u 100Base-TX
EIA/TIA RS-232/422/485
|
| Aprobare reglementară |
RoHS |
| Testul de stabilitate |
IEC60068-2-32(Free fall),
IEC60068-2-27(Shock),
IEC60068-2-6(Vibration)
|
| Notă |
Reset Button at the front panel for reset to factory default |
