| Specificații hardware |
| Versiunea hardware |
V2 |
| Interfață de atașament |
PCI Express rev. 2.0 specification x4 Interface |
| Interfața media |
SFP+ Connector |
| Opțiunile modulelor optice |
LRM, LR, SR |
| Memorie |
1Mbit internal memory |
| Jumbo Frame |
9K / 16K Bytes |
| Indicatoare LED |
LNK / ACT per port |
| Dimensiuni (L x Î x H) |
62 x 83 x 22 mm |
| Greutate |
47g |
| Consumul tipic de energie |
4 watts |
| Funcții avansate |
| Layer 2 Features |
IEEE 802.3x Flow Control support
IEEE 802.1Q VLAN support
|
| Suport pentru sistemul de operare |
Windows Server 2008R2 64bits
Windows Server 2012 64bits
Windows 7 32 / 64bits
Windows 8 32 / 64bits
Linux (2.6x to 3.8.0)
VMware® ESX 4.x
|
| Conformitatea standardelor |
| Reglementarea conformității |
FCC Part 15 Class B, CE |
| Respectarea standardelor |
IEEE 802.3ae: 10Gbps Ethernet
IEEE 802.3x: Flow Control and Back Pressure
IEEE 802.1Q: VLAN Tagging
|
| Mediu inconjurator |
| De operare |
Temperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
|
| Depozitare |
Temperature: -10 ~ 85 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
|
| Pachet |
| Conținutul pachetului |
● ENW-9801 Server Adapter
● Quick Installation Guide
● CD-ROM (Driver & User’s Manual)
● Low Profile Bracket
|
