| Hardware Specification |
| Standards |
IEEE 802.3, 10Base-T
IEEE 802.3u, 100Base-TX, 100Base-FX
IEEE 802.3x, Flow Control
IEEE 802.1p, Class of Service |
| Copper Port |
1 x 10/100Base-TX RJ-45 port
Auto-negotiation, Auto-MDI/MDI-x |
| Optical Port |
1 x 100Base-FX |
| Fiber Connector |
FT-902 : SC / Multi-mode / 2km
FT-902S15 : SC / Single Mode / 15km
FT-902S35 : SC / Single Mode / 35km
FT-902S50 : SC / Single Mode / 50km
FT-905A : SFP / Vary on transceiver module
FT-906A20: WDM SC / Single Mode / 20km
FT-906B20: WDM SC / Single Mode / 20km
|
| Optic Wavelength |
FT-902: 1310nm
FT-902S15: 1310nm
FT-902S35: 1310nm
FT-902S50: 1310nm
FT-905A: Vary on transceiver module
FT-906A20: TX: 1310nm, RX: 1550nm
FT-906B20: TX: 1550nm, RX: 1310nm
|
| Launch Power (dBm) Max. |
FT-902: -14
FT-902S15:0
FT-902S35:-8
FT-902S50:0
FT-905A:NA
FT-906A20:-8
FT-906B20:-8 |
| Launch Power (dBm) Min. |
FT-902: -20 (62.5/125µm), -23.5 (50/125µm)
FT-902S15: −20
FT-902S35: -15
FT-902S50:-5
FT-905A:NA
FT-906A20:-14
FT-906B20:-14 |
| Receive Sensitivity (dBm) |
FT-902: -31.8
FT-902S15: -32
FT-902S35:-34
FT-902S50: -35
FT-905A:NA
FT-906A20:-31
FT-906B20:-31 |
| Maximum Input power (dBm) |
FT-902: -14
FT-902S15:0
FT-902S35:0
FT-902S50:0
FT-905A: NA
FT-906A20:0
FT-906B20:0 |
| Speed-Twisted-pair |
10/20Mbps for Half/Full-Duplex
100/200Mbps for Half/Full-Duplex |
| Speed-Fiber-optic |
200Mbps for Full-Duplex |
| Cable-Twisted-pair |
10Base-T: 2-pair UTP Cat. 3, 4, 5, up to 100 m
100Base-TX: 2-pair UTP Cat. 5, up to 100 m |
| Cable-Fiber-optic cable |
• 50/125µm or 62.5/125µm multi-mode fiber cable, up to 2km.
• 9/125µm single-mode cable, provides long distance for
15/20/35/50km or longer (very on SFP module) |
| LED Indicators |
PWR,
TP LINK/ACT, TP FDX, TP SPEED
Fiber LINK/ACT, Fiber FDX |
| Power Consumption |
5.5 Watts (maximum) |
| Power Input |
5V/2A |
| Dimension (W x D x H) |
93 x 69 x 25 mm |
| Operator Environment |
Operating temperature: 0 to 50 degree C
Humidity: 10~90% non-condensing |
| Storage Environment |
storage temperature: -25 to 70 degree C
Humidity: 10~90% non-condensing |
| Emission |
FCC Class A, CE Class B |
