| Hardware Specification |
| 10/100Base-TX Ports |
5 |
| Dimension (W x D x H) |
135 x 87 x 32 mm |
| Weight |
438g |
| Power Requirement |
12~48 VDC, Redundant power with polarity reverse protection function |
| Power Consumption / Dissipation |
3.9 Watts / 13BTU |
| Installation |
DIN rail kit and wall mount ear |
| Alarm |
rovides one relay output for power fail
Alarm Relay current carry ability: 3A @ DC 30V |
| Switch Specification |
| Switch Processing Scheme |
Store-and-Forward |
| Address Table |
2K entries |
| Flow Control |
Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex |
| Switch fabric |
1Gbps |
| Throughput (packet per second) |
0.74Mpps |
| Network cables |
10/100Base-TX:
Cat. 3, 4, 5, 5e, 6 UTP cable (100meters, max.)
EIA / TIA-568 100-ohm STP (100meters, max.) |
| Standards Conformance |
| Standards Compliance |
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full-duplex flow control
|
| Regulation Compliance |
FCC Part 15 Class A, CE |
| Stability testing |
IEC60068-2-32(Free fall),IEC60068-2-27(Shock),IEC60068-2-6(Vibration) |
| Environmental Specification |
| Temperature |
Operating: -40~75 Degree C
Storage: -40~75 Degree C
|
| Humidity |
Operating: 5~90%
Storage: 5~90% (Non-condensing) |
