| Produs |
| porturi |
WAN
1 x 100Base-FX port
LAN
4 x 10/100Base-TX port
|
| Interfață optică |
Connector
FRT-401: SC
FRT-401S15: SC
FRT-405: SFP
Mode
FRT-401: Multi-mode
FRT-401S15: Single-mode
FRT-405: Vary on module
Distance
FRT-401: 2km
FRT-401S15: 15km
FRT-405: Vary on module
|
| Lungime de undă optică |
FRT-401: 850nm
FRT-401S15: 1310nm
|
| Lansarea puterii (dBm) |
Max.
FRT-401: -14
FRT-401S15: -7
Min.
FRT-401: -19.0
FRT-401S15: -20
|
| Primiți sensibilitate |
FRT-401: -34.5
FRT-401S15: -28
|
| Putere maximă de intrare |
FRT-401: -14
FRT-401S15: -8
|
| Cablu de fibra optica |
• 50/125μm or 62.5/125μm multi-mode fiber cable, up to 2km.
• 9/125μm single-mode cable, provide long distance for 15/20/35/50km or longer (very on SFP module)
|
| Indicatoare LED |
PWR, Fiber, LAN1-4 |
| Buton |
1 x RESET button |
| Software-ul |
| Max. sesiuni |
4096 |
| Protocol / Caracteristică |
Router and Bridge mode
Static Routing and RIPv1/2
DMZ and Virtual Server
802.1D
802.1Q VLAN support
QoS
SNTP
DHCP Server / Client
IGMP Proxy and DNS Proxy
Universal Plug and Play (UPnP) Compliant
DDNS (Dynamic Domain Name System)
|
| VPN |
VPN Pass-Through |
| Securitate |
Built-in NAT Firewall
MAC / IP/ Port Filtering
Content Filtering
SPI Firewall support
Password protection for system management
|
| administrare |
Web-Based configuration
Available Syslog support
TR-069*
SNMP v1/v2c
TS-1000 and 802.3ah OAM support
|
| Specificația mediului |
| Dimensiune (L x Î x H) |
186 x 143 x 35mm |
| Putere |
12V DC, 1A |
| Temperatură / Umiditate |
Operating: 0~50 Degree C, 5~90% (non-condensing)
Storage: -10~70 Degree C, 0~95% (non-condensing)
|
| emisie |
FCC, CE |
| * Îmbunătățirea funcției prin viitoarea firmware actualizabilă. |
